Trusted Dobinsons GVM Facility
Dobinsons GVM Upgrade – Toyota HiLux AN2 / N90
GVM to 3,800 kg · Federally approved · Supplied & fitted at Smeaton Grange
More legal payload for your new HiLux
The new-generation HiLux (AN2 / N90) gets Dobinsons’ biggest ute rating at 3,800 kg GVM. The kit includes upper control arms and Cat 6 indicators as standard, so it is a complete package for HiLux owners adding canopies, drawers and touring gear.
As an authorised Dobinsons GVM fitter, we replace the factory springs and shocks with a matched, federally approved Dobinsons package. You choose spring rates to suit your accessories and a shock to suit how you drive, and we fit it, update the compliance and send you on your way.
- New GVM: 3,800 kg – 4x4 only. Excludes plug-in hybrid and some cab chassis variants.
- Towing: GCM stays at the factory figure
- Approval: Pre-rego and post-rego*
Pricing
3,800 kg GVM · Prices include GST · Supplied & fitted · Choose your shock
*Further charges for state based engineering may apply. Spring rates are chosen at no extra cost to suit your accessories.
Specifications
| New GVM | 3,800 kg |
|---|---|
| Front axle limit | 1,700 kg |
| Rear axle limit | 2,100 kg |
| GCM | Unchanged from factory |
| Wheels & tyres | OEM wheels and tyres are compliant |
| Category | Changed to NB1 |
| Indicators | Cat 6 indicators included; Cat 5 indicators made non-operable |
| Registration | Pre-rego and post-rego* |
Front coil spring options
- 40 mm lift – up to 60 kg
- 50 mm lift – up to 60 kg
- 50 mm lift – 70–100 kg
Rear leaf spring options
- 45 mm lift – 300–350 kg constant load (touring option)
- 45 mm lift – 580 kg constant load
Shock options
- Twin Tube Nitro-Gas
- IMS
- MRR
What's in the kit
- 2 x front coil springs
- 2 x front shock absorbers
- 2 x rear leaf springs
- 2 x rear shock absorbers
- 2 x upper control arms
- 2 x rear shackles
- 1 x rear shackle bush kit
- 4 x rear U-bolts
- 2 x rear shackle pins
- 2 x tailshaft spacer kits
- 1 x rear headlight adjuster (SR5)
- 2 x Cat 6 indicators
Note: Excludes 4x2 variants.
Pre-rego or post-rego?
Pre-registration
Fitted before first registration under the federal approval. Your vehicle is recognised Australia-wide for life, and it is usually the simplest and cheapest path if you are buying new.
Post-registration
For vehicles already on the road. An approved signatory certifies the upgrade under NSW rules and your rego is updated. Further charges for state based engineering may apply, and the vehicle may need re-certifying if it moves interstate.
Why Project Overlander
Trusted GVM facility
We fit Dobinsons GVM upgrades in-house at our Smeaton Grange workshop – fitted by our own technicians, not sub-contracted.
Paperwork handled
We organise the compliance plate, certification and rego update, whether your vehicle is new or already on the road.
Build it once
Combine your GVM upgrade with trays, canopies, drawers, long range tanks and 12V from the same workshop, so the whole build is planned around your new payload.
new HiLux GVM FAQs
Does it suit every new HiLux?
It suits 4x4 models only, and excludes the plug-in hybrid and some cab chassis variants. Send us your exact variant and we will confirm.
Are upper control arms included?
Yes. On the AN2 / N90 HiLux the upper control arms are part of the kit.
What does the price include?
Prices include GST and cover the Dobinsons kit supplied and fitted by an authorised Dobinsons GVM fitter at our Smeaton Grange workshop. Further charges for state based engineering may apply, and load rated wheels and tyres are extra where a kit requires them.
How do I get started?
Send us an enquiry below with your vehicle, what you carry and whether it is registered. We will confirm the right kit and spring rates and book you in.
